AM/AMA Aramid paper+Polyester Film+Aramid paper
Properties and Application:
AM/AMA is made of one or two layers of aramid paper with one layer of electrical grade polyester film, which has good
dielectric properties, high heat resistance and mechanical strength, and suitable for electric motors as slot, phase, turn-
to-turn, liner insulation in F-class Motor. The AMA is the good lower cost insulation solution way to replace NMN6640.
Main Specification:
AM
|
Properties |
Value |
||||||||||
|
Structure (A+M)(mil) |
21 |
22 |
23 |
24 |
25 |
27H |
210 |
212 |
214 |
||
|
Structure Thickness (mm) |
Aramid |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
|
|
PET Film |
0.025 |
0.05 |
0.075 |
0.10 |
0.125 |
0.188 |
0.25 |
0.30 |
0.35 |
||
|
Nominal Thickness(mm) |
0.08 |
0.11 |
0.13 |
0.16 |
0.18 |
0.25 |
0.31 |
0.36 |
0.41 |
||
|
Thickness Tolerance +/- % |
15% |
10% |
|||||||||
|
Specific Weight(g/m2) |
95 |
125 |
160 |
190 |
230 |
320 |
390 |
470 |
550 |
||
|
Weight Tolerance +/- % |
12% |
||||||||||
|
Tensile Strength (N/cm) |
MD ¡Ý |
100 |
130 |
140 |
160 |
180 |
230 |
280 |
300 |
340 |
|
|
TD ¡Ý |
70 |
80 |
90 |
100 |
120 |
200 |
300 |
310 |
320 |
||
|
Elongation (%) |
MD ¡Ý |
15 |
20 |
||||||||
|
TD ¡Ý |
20 |
||||||||||
|
Breakdown Strength (KV) |
5 |
7 |
9 |
10 |
12 |
15 |
18 |
20 |
21 |
||
|
Bonding Strength at 25c. |
No Delamination |
||||||||||
|
Bonding Strength at 155 + 2 C |
No Delamination, No Blister, No Adhesive Flow |
||||||||||
AMA
|
Properties |
Value |
|||||||||||||
|
Structure (A+M+A)(mil) |
212 |
222 |
232 |
242 |
252 |
27H2 |
2102 |
2122 |
2142 |
333 |
353 |
37H3 |
||
|
Structure Thickness (mm) |
Aramid |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.075 |
0.075 |
0.075 |
|
|
Pet |
0.025 |
0.05 |
0.075 |
0.10 |
0.125 |
0.188 |
0.25 |
0.30 |
0.35 |
0.075 |
0.125 |
0.188 |
||
|
Aramid |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.05 |
0.075 |
0.075 |
0.075 |
||
|
Nominal Thickness(mm) |
0.14 |
0.17 |
0.19 |
0.22 |
0.24 |
0.31 |
0.37 |
0.40 |
0.47 |
0.24 |
0.30 |
0.35 |
||
|
Thickness Tolerance +/- |
15% |
10% |
15% |
10% |
||||||||||
|
Specific Weight(g/m2) |
145 |
175 |
215 |
235 |
275 |
365 |
455 |
525 |
595 |
255 |
325 |
420 |
||
|
Weight Tolerance +/-g/m2 |
20 |
20 |
30 |
30 |
35 |
45 |
50 |
60 |
70 |
35 |
40 |
50 |
||
|
Tensile Strength (N/cm) |
MD ¡Ý |
100 |
160 |
170 |
190 |
220 |
270 |
330 |
360 |
400 |
190 |
270 |
320 |
|
|
TD ¡Ý |
80 |
90 |
110 |
120 |
150 |
200 |
300 |
320 |
350 |
180 |
200 |
250 |
||
|
Elongation (%) |
MD ¡Ý |
15 |
20 |
15 |
20 |
|||||||||
|
TD ¡Ý |
20 |
25 |
20 |
25 |
||||||||||
|
Breakdown Strength (KV) |
6 |
8 |
11 |
12 |
14 |
18 |
20 |
23 |
25 |
12 |
15 |
20 |
||
|
Bonding Strength at 25c. |
No Delamination |
|||||||||||||
|
Bonding Strength at 155 + 2 C |
No Delamination, No Blister, No Adhesive Flow |
|||||||||||||
Product supply:
1, Width: 980~1000 mm
2, Packing: 50 Kg/Roll, In Carton and Pallet
3. MOQ: 1,000 Kg in a lot, and 500 Kg each size..
¡¡
Note:
1. Above values are the accumulative typical ones by recognized testing method, but, in order to ensure you to select our products
properly, please refer to above specification and test the samples based on your using purpose or feel free to contact our engineers
for further and better understanding.
2. The color is confirmed by samples.
¡¡
¡¡
____________________________________________
