1\ All type of flexible laminated composite for slot insulation of motor and layer insulation for transformer

Item  Color Description Thickness mm Insulation Grade Detail information
Fish paper and polyester film composite 6520 blue/brown fish paper+ polyester film 0.08~0.5 E enter
Polyester non-woven fabric (Dacron) and polyester film composite  6630,6631,6632 white Dacron + Polyester film + Dacron 0.09~0.5 B enter
white Dacron + Polyester film +Dacron + Polyester film  (four layers) 0.05~0.45 B enter
white Dacron + Polyester film 0.45~0.9 B enter
Modify polyester non-woven fabric (Dacron) and polyester film composite  6641, 6642 white,light blue,pink, green,   yellow Dacron + Polyester film + Dacron 0.09~0.45 F enter
Dacron + Polyester film + Dacron double coated with 100% epoxy resin 0.09~0.45 enter
Pre-preg polyester non-woven fabric and polyester film composite  DMD-P red,brown Dacron + polyester film +Dacron double coated with B-stage epoxy resin 0.16~0.5 F enter
Nomex*1 paper and polyester film composite 6640 white Nomex paper + polyester film +Nomex paper 0.13~0.45 F enter
Pre-preg Nomex paper and polyester film composite 6640-P white Nomex paper + polyester film +Nomex paper coated with B-stage epoxy resin 0.15~0.5 F enter
Polyester film and Glass cloth composite white Glass cloth +polyester film 0.09~0.45 F enter
Glass cloth +polyester film + glass cloth 0.15~0.50 *2
Polyester film +glass cloth +polyester film 0.15~0.50 enter
Polyimide film and Glass cloth composite amber Glass cloth +polyimide film 0.09~0.30 H enter
Glass cloth +polyimide film +glass cloth 0.15~0.45 enter
Polyimide film +glass cloth + polyimide film 0.13~0.30 enter
Pre-preg polyimide film and polyester non-woven fabric composite pink Polyimide film +polyester non-woven fabric coated with B-stage resin 0.15~0.18 H enter
Nomex* paper and polyimide film composite 6650 pink Nomex paper + polyimide film +Nomex paper 0.13~0.45 H enter
Aramid paper and polyester film composite white Aramid paper + polyester film +Aramid paper 0.13~0.45 F enter
Aramid paper and polyimide film composite pink Aramid paper + polyimide film +Aramid paper 0.13~0.50 H enter
Multilayer polyester film composite milk two to five layers polyester film 0.5~1.3 F enter
Multilayer polyimide film composite amber Two layers, three layers polyimide film composite 0.05~0.45 H enter
Pre-preg Nomex paper white Nomex paper double coated with B-Stage resin 0.13~0.15 H enter
Multilayer aramid paper composite white multilayer aramid paper 0.15~1 C enter

*1Nomex is the remarkable of EI Dupont.

*2 This kinds of product are accord to your request.

2\ Type of the Polyester Non-woven fabric (fleece, Dacron)

item

color

Application thickness mm weight g/m2 Max width mm Detail information
Polyester non-woven ST7030

White

Air and liquid filter materials 0.13~0.30 75~200 1800 enter
Electrical polyester non-woven ST7030T Best pregnant capacity used in the HV of the dry transformer 0.13~0.23 80~120 1800 enter
Electrical polyester non-woven ST7031 The base materials for making DMD,DMD100. also can be used in the cable and magnet wire. 0.038~0.13 21~80 2040 enter
Electrical polyester non-woven ST7031A The lightest weight and the thinnest thickness for cover of the VPI mica tape. 0.025 15 1020 enter
Electrical polyester non-woven ST7031T Best pregnant and good tensile strength capacity used for  adhesive tape replace the cotton paper. 0.038~0.075 21~45 2040 enter
Electrical polyester and aramid non-woven ST7032

light yellow

Air filter material and the higher temperature resistant capacity than normal polyester ST7031 0.045 35 2040 enter

3\ Type of the Polyimide film

item color Application thickness mm Width mm Detail information
Polyimide film 6050 similar to Kapton HN* Amber The raw materials of polyimide adhesive tape, the composite of 6650, and the magnet wire. 0.025~0.23 520~1040 enter
Polyimide film coated with FEP resin  similar to Kapton FN Amber For warping magnet wire and  for flexible heater. 0.031~0.075 6~500 enter

*Kapton is the remarkable of EI Dupont

4\ Type of the adhesive tape

item color Description thickness mm Width mm Detail information
Polyimide silicon adhesive tape ST650 Amber Polyimide film single side coated with silicon adhesive 0.031~0.13 3~500 enter
Polyimide silicon adhesive tape ST650-RL Amber Polyimide film single side or double side coated with silicon adhesive composite with the fluorine release polyester film 0.031~0.13 3~500 enter
Polyimide acrylic adhesive tape ST640 Amber Polyimide film single side coated with acrylic  adhesive 0.031~0.013 3~500 enter
Glass cloth silicone adhesive tape ST690 White Glass cloth  single side coated with silicon adhesive 0.17 6~500 enter
Glass cloth silicone adhesive tape with release film ST690-RL White Glass cloth  single side or double side coated with silicon adhesive  composite with the fluorine release polyester film 0.20~0.25 6~500 enter
Glass cloth silicone adhesive tape ST790 White Glass cloth  single side coated with acrylic adhesive 0.17 6~500 enter

5\ Risen and Powder coating materials

item Description Detail information
Top-coated powder materials DC115 DC115 Inner-Coated Powder for Industrial Pipe enter
Top-coated powder materials DC150 DC150 Inner-Coated Powder for Industrial Pipe  higher temp. application  Max 150degree enter
Top-coated powder materials DC204 DC204 Inner-Coated Powder for Industrial Pipe  higher temp. application Max 204degree enter
Top-coated powder materials DTK70 DTK70 Inner-Coated Powder for Industrial Pipe  higher temp. application Max 105degree enter
Top-coated powder materials DTK69 DTK69 Inner-Coated Powder for Industrial Pipe  higher temp. application Max 130degree enter
Top-coated powder materials DPC156 DPC156 Inner-Coated Powder for Industrial Pipe  higher temp. application Max 150degree enter
Top-coated powder materials DTK34P DTK34P Inner-Coated Powder for Industrial Pipe  higher temp. application Max 204degree enter
Undercoated resin PC8007 The resin can be used for coupling agent with the DC xxx series powder coating
